Erba Chem-5X

Erba Chem 5X:-

Product Description: Erba Chem 5X is a low cost, compact, high performance semi automated analyzer for all routine Clinical chemistry, Electrolytes, Immunoturbidimetric assays.

Product Features:

• Semi automated analyzer
• Multi-point calibration with graphical display
• Repeat measurement with read key
• USB connectivity to external printer and PC
• Monochromatic & bichromatic measurement
• Built- in self diagnosis with help key facility
• Dual cuvette system and inbuilt thermal printer

Product Applications:

• Entire range of Clinical Chemistry tests including Electrolytes and Immunoturbidimetric Assays.

Technical Specification:

• 222 open user-defined test programs

  9 Assay modes

  • 1 Point Linear
  • 2 Point Linear
  • 1 Point Non Linear
  • 2 Point Non-linear
  • Rate A Linear
  • Rate A Non-Linear
  • 1 Point Sample Blank Linear
  • 1-Point Sample Blank Non-Linear
  • Absorbance

  Mono & Bichromatic measurement

  Photometric range from 0 to 3.0 OD

  Photometric resolution up to 0.0001

  Automatic zero setting

  Static Photometer: 340-630 n.m.

  Wavelength: 340, 405, 505, 546, 578, 630 n.m.  + 2 Optional positions

  Multi-Point calibration with graphical display

  Levy-Jennings graph for quality control

  5000 Test patient results storage

  Peristaltic pump aspiration system with calibration facility

  Dual cuvette system:

  • Flow cell volume-33 µl
  • 10 mm external glass / Polystyrene

  Aspiration volume from 100 to 2997 µl

  Temperature control at 20° to 40° in step of  1°C

  Repeat measurement by read key

  Collated report date wise, ID wise (Alphanumeric)

  Inbuilt Thermal Printer

  Direct Printer Connectivity through USB Port

  USB Connectivity to PC

  Connectivity to external Incubator (Optional with 16 position)
